Praying Mantis Arm Car Carrier Trailer for High-Capacity Vehicle Transport
The Praying Mantis Arm Car Carrier Trailer is an advanced vehicle transport solution featuring a lifting arm structure that maximizes loading capacity and flexibility. It is ideal for high-efficiency automobile logistics and long-distance fleet transportation.
Praying Mantis Arm Car Carrier Trailer Detailed Description
The Praying Mantis Arm Car Carrier Trailer is a premium car transport solution engineered for maximum loading capacity and operational flexibility. Its distinctive lifting arm (praying mantis arm) structure allows the front section of the trailer to be raised or lowered, creating additional loading space and optimizing vehicle arrangement.
Compared with standard car carriers, this design significantly improves space utilization and loading efficiency, making it possible to transport more vehicles per trip while maintaining safe clearance and balance. The hydraulic lifting system operates smoothly and reliably, enabling faster loading and unloading.
Constructed with high-strength steel, precision welding, and reinforced pivot points, the praying mantis arm trailer is designed to withstand repeated lifting operations and demanding road conditions, making it a preferred choice for professional automobile logistics operators.
Suitable for the transportation of cars,commercial vehicles,other passanger cars.
(a)This system mainly adopts the transportation vehicles semi-trailer rectangular pipe welded together frame structure, the overall high intensity, light weight, good appearance, have fully enclosed type, half hanging, semi-enclosed and frame type to wait for a few kinds structure, the use of safe and reliable
(b)The model fully absorbed the features of similar domestic and foreign products, adopt unique lifting system, the key part adopts renowned domestic and foreign products, load ability and high reliability
(c)The whole upper platform can be used on certain height, thus the can carry a different specifications od cars, MPV and SUVs and pickup truck, miniature passenger vehicles such as 5-10 vehicles. User's special customized vehicles can possess such special vehicle smoked full function, can transport various kinds of automobiles, return distribution, and other functions. The car is realized commodity car sales ideal tool for zero miles per hour
| General | ||||||
| Overall Dimension | 15000mm*2500mm*3800mm(Dimensions can be designed) | |||||
| Number of Car | 6(car quantity can be optional,6-12 cars) | |||||
| Total Weight | 11000kg | Pay Load | 40ton | |||
| Tell us the car outside dimensions,car carrier trailers can be designed | ||||||
| Running Gear | ||||||
| Suspension | Tri-axle 10-pcs leaf spring suspension with equalizer beam | |||||
| (Air suspension) | ||||||
| Tires | 10.00R20/8.25R20/1100R20, 12units | |||||
| Axles | FUWA axle, 13T capacity(BPW,YORK,SAF optional) | |||||
| Brakes | Dual lines pneumatic brake system, WABCO Emergency | |||||
| Relay Valve; T30/30+T30 air chamber; parking brake | ||||||
| Under Frame | ||||||
| Main Beam | Q345B steel,Height 500, upper 18mm, | |||||
| lower 18mm. Mid web 10mm | ||||||
| Cross Beam | Mild Alloy Q235 | |||||
| King Pin | Size: 50# (2'') or 90#(3.5''); Type: welded or assembled | |||||
| Landing Gear | Single side operation or double side operation, | |||||
| Static capacity 28Ton | ||||||
| Appendix | 1 tool box, length 1.0m | |||||
| Electrical & Paint | ||||||
| Electrical | Rear light, rear reflector, turn indicative light, side reflector, | |||||
| fog lamp, number plate light | ||||||
| Lights & Reflectors | 24V, 7 lines | |||||
| Wiring | ISO standard air connector, 24V 7 pin plug socket | |||||
| Air/Elec. Connector | Color upon request | |||||
| Paint | According to your requirements | |||||
- Streamlined body: Adopting aerodynamic optimisation design, the streamlined body effectively reduces wind resistance, improves fuel economy and reduces driving noise, creating a more comfortable driving environment for drivers.
- High-strength aluminium alloy material: The body frame is made of high-strength aluminium alloy, which not only reduces the weight of the whole vehicle and improves fuel efficiency, but also enhances the corrosion resistance and durability of the vehicle to ensure the stability of long-term use.
- Modular design: The unique modular loading platform design can flexibly adjust the loading position according to the size of different models, adapting to the transport needs of a variety of passenger cars and improving loading efficiency and flexibility.
- Intelligent Lighting System: Equipped with LED intelligent lighting system, it not only improves the safety of night driving, but also automatically adjusts the brightness through intelligent sensor technology, which is energy-saving and environmentally friendly.
Praying Mantis Arm Car Carrier Trailer Key Advantages
✅ Higher Loading Capacity
Innovative lifting arm design
Optimized vehicle layout for maximum efficiency
✅ Flexible Loading Configuration
Adjustable front deck height
Suitable for vehicles of different sizes
✅ Advanced Hydraulic System
Stable and smooth lifting operation
Reduced manual intervention
✅ Export-Grade Build Quality
Reinforced structural components
Designed for intensive, long-term use
Praying Mantis Arm Car Carrier Trailer Application Scenarios
- Large-scale automobile logistics companies
- OEM and distributor vehicle transport
- Export vehicle transportation
- High-frequency long-haul operations
- Fleet and dealership supply chains
Praying Mantis Arm Car Carrier Trailer Optional Configurations
- Hydraulic system brand options
- Deck length and angle customization
- Axle, suspension, and braking system choices
- Vehicle fixing and protection systems
- LHD / RHD layout
- Custom paint and logo branding
Why Choose Us
- Advanced Engineering Capability
We design and manufacture complex lifting-structure trailers with proven reliability.
- Custom Solution Provider
Each trailer can be tailored to your transport volume, vehicle types, and local regulations.
- Global Export Experience
Extensive experience supplying car carrier trailers to multiple international markets.
- Long-Term Cooperation Focus
We aim to build stable partnerships, not one-time transactions.
Semi trailer manufacturer Services
- Technical consultation & design optimization
- Customized production
- Factory inspection & testing
- Export packing and shipping support
- After-sales technical guidance and spare parts
