Liquid Tank Trailer for Safe Bulk Liquid Transportation
Liquid Tank Trailer Detailed Description
The liquid oxygen trailer is a specialized semi-trailer engineered for transporting bulk liquid products under demanding road and climate conditions. It is widely used in industries such as chemical transport, industrial liquids, food-grade liquids, and other non-hazardous or designated liquid cargo applications.
The tank body features a fully sealed structure, ensuring excellent leak prevention and cargo protection during transit. Combined with a high-strength steel or alloy chassis, the trailer maintains superior stability even under full-load and long-haul operations.
The internal tank design is optimized to reduce liquid surge and improve driving safety. Precision welding, strict quality control, and export-grade manufacturing standards ensure long service life and low operating costs. Multiple customization options allow the trailer to be adapted to different liquid types, transport regulations, and market requirements.
Technical Specifications(Custom configurations available upon request)
| Dimension(Optional) | Axle No. | Rated Load (kg) | Tire No. | Tire Size |
| 10000-30000liters/10-30cbm | 2 | 40000 | 8 | 825R20 1000R20 1100R20 1200R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier) |
| 30000-60000liters/30-60cbm | 3 | 60000 | 12 | |
| Above 60000liters/60cbm | 4 | 75000 | 16 | |
| Products | LPG, Butane , Propane | |||
| Fluid property | flammable | |||
| Design temperature | -40°C to 50°C | |||
| Design pressure | 1.61MPa | |||
| Filling weight per volume | 420Kg/m3 | |||
| Maximum filling weight | 24486Kg | |||
| Compartments | One | |||
| Baffle inside the tank | 14-off bolted plate , 5mm | |||
| Shape | Cylindrical ; Ellipse head | |||
| Fire extinguisher | 2 With red box | |||
| Flaw detection | 100% Flaw detection | |||
| Hydrostatic test | 2.1MPa | |||
| Manhole | 1 ; On top | |||
| Safty Valve | 1 | |||
| Suspension system | Leaf spring 10pcs | |||
| Landing legs | 28Ton | |||
| 7-Pin Socket | 24V 7-pin socket | |||
| LED Lamp | All kinds of lamp | |||
| Kingpin | 90 and 50# Bolt-atble | |||
| Small Tool box | 1 | |||
| Wheel carrier | 1 | |||
| Corrosion allowance | 1.0mm | |||
| Magnaflux | Aim at welding place flaw detection can not cover | |||
| Heat treatment | Overall heat treatment in a furnace , 500°C to 560°C | |||
| Major materials bearing pressure | Tanker body : Q345R , 12.5mm,End plate : Q345R , front:10mm,Rear:12.5mm ,Main Beam : T700 | |||
Liquid Tank Trailer Key Advantages
✅ Safe & Sealed Tank Structure
Fully sealed tank body design
Reduces leakage risk and environmental impact
✅ Stable Transportation Performance
Optimized tank geometry to minimize liquid sloshing
Improved driving stability and braking performance
✅ High-Strength Chassis
Reinforced main beams and load-bearing structure
Designed for heavy-duty and long-distance transport
✅ Export-Grade Manufacturing
Precision welding and strict quality inspection
Built to meet international transport standards
Liquid Tank Trailer Application Scenarios
- Bulk liquid logistics transportation
- Industrial liquid delivery
- Chemical and specialty liquid transport
- Food-grade liquid transportation (configurable)
- Regional distribution and long-haul freight
- Specific liquid compatibility can be customized according to customer requirements.
Liquid Tank Trailer Optional Configurations
- Tank material options (carbon steel / stainless steel / aluminum alloy)
- Tank capacity and compartment design
- Internal anti-wave baffle configuration
- Loading and unloading system options
- Valve, manhole, and pipeline specifications
- Axle, suspension, and braking system selection
- Custom paint color and logo branding
Why Choose Our Liquid Tank Trailer
- Professional Semi trailer companies
Years of experience in liquid transport trailer design and production.
- Engineering-Oriented Design
Every structure is optimized for safety, durability, and real transport scenarios.
- Export Market Experience
Familiar with international logistics requirements and regional regulations.
- Reliable Quality & Long Service Life
Strict quality control from raw materials to final inspection.
Our Services
- Custom heavy duty semi trailers design based on transport requirements
- OEM & ODM manufacturing support
- Technical consultation before order confirmation
- Pre-shipment inspection and quality documentation
- Export packing and international shipping coordination
- Spare parts supply and after-sales technical support
